6024 & 6044 Series Operations Manual Rev F 02/14/12 Page 18 of 56
Installing Carboy water system (BOTL301)
Incubators can be purchased with an optional 2.5 gallon carboy water system. The
carboy system is preassembled and shipped inside the chamber. The four ¼” bolts
required to mount the carboy to the unit will be mounted in the left hand side of the
chamber. Remove the carboy assembly from inside the chamber and attach it to the
chamber using the ¼” bolts.
Attach the preassembled tubing provided with the carboy to the water inlet on the rear of
the chamber.
Fill the carboy with water as described in the “connecting a water supply” section of the
manual.
¼” Bolts
(4 total)
Tubing connects/
disconnect to
carboy
Tubing to water
inlet
