Allen & Heath User Guide for XONE:DX with Serato ITCH 1.7 39
SOFTWARE OVERVIEW - EFFECTS
1 2 3 4 5 6 7
CURRENT EFFECT
The currently selected effect applied to the channel.
1
DEPTH
The amount of CURRENT EFFECT applied to the selected audio sources.
2
PARAMETER 2 (INTENSITY)
The second parameter for the CURRENT EFFECT.
4
TIME
Displays the time division for the CURRENT EFFECT.
5
AUTO A
Displays which source tempo the CURRENT EFFECT is following. Will show MASTER
when a track is syncing to Master Clock.
6
PARAMETER 1 (MOD DEPTH)
The first parameter for the CURRENT EFFECT.
3
CUE
Displays if the effect is being sent to the headphone cue for auditioning.
7
