Advanced Features
Virtual Servers Screen
The Virtual Servers screen is reached by the Virtual Servers link on the Advanced screen. An
example screen is shown below.
Figure 41: Virtual Servers Screen
This screen lists a number of pre-defined Servers, and allows you to define your own Servers.
Details of the selected Server are shown in the "Properties" area.
Data - Virtual Servers Screen
Servers
Servers This lists a number of pre-defined Servers, plus any Servers you
have defined. Details of the selected Server are shown in the
"Properties" area.
Properties
Enable Use this to Enable or Disable support for this Server, as required.
PC (Server) Select the PC for this Server. The PC must be running the appro-
priate Server software.
Protocol Select the protocol (TCP or UDP) used by the Server.
Internal (LAN)
Ports Enter the range of port numbers which the Server software is
configured to use.
