AirLive WL1600GL Broadband Router
Figure 33: Access Control - Services
Data - Services Screen
Available Services
Available Services This lists all the available services.
"Delete" button Use this to delete the selected Service from the list.
Add New Service
Name Enter a descriptive name to identify this service.
Type Select the correct type for this Service.
Start Port If the "Type" (above) is TCP, UDP, or TCP/UDP, enter the port
number for this Service. If a port range is required, enter the begin-
ning of the range here, and the end of the range in the "Finish Port"
field.
Finish Port If the "Type" (above) is TCP, UDP, or TCP/UDP, this field can be
used to enter the end of range of port numbers. This can be left blank
if not required.
ICMP Type If the "Type" (above) is ICMP, enter the ICMP type here. Otherwise,
this field should be left blank.
