AirLive WL1600GL Broadband Router
Connection Status - PPTP
If using PPTP (Peer-to-Peer Tunneling Protocol), a screen like the following example will be
displayed when the "Connection Details" button is clicked.
Figure 27: PPTP Status Screen
Data - PPTP Screen
Connection
Physical Address The hardware address of this device, as seen by remote devices on
the Internet. (This is different to the hardware address seen by
devices on the local LAN.)
IP Address The IP Address of this device, as seen by Internet users. This address
is allocated by your ISP (Internet Service Provider).
Connection Status
• This indicates whether or not the connection is currently estab-
lished.
• If the connection does not exist, the Connect button can be used
to establish a connection.
• If the connection currently exists, the Disconnect button can be
used to break the connection.
44
