AirLive WL1600GL Broadband Router

Figure 50: Routing Screen

Data - Routing Screen

RIP

Enable RIP VI

Check this to enable the RIP (Routing Information Protocol) feature
of the Wireless Router.

The Wireless Router supports RIP 1 only.

Static Routing

Static Routing
Table Entries

This list shows all entries in the Routing Table.
• The "Properties" area shows details of the selected item in the

list.

• Change any the properties as required, then click the "Update"

button to save the changes to the selected entry.

96
