Operation and Status
connection, a "Connection Log" may also be available.
LAN
IP Address The IP Address of the Wireless Router.
Network Mask The Network Mask (Subnet Mask) for the IP Address above.
DHCP Server This shows the status of the DHCP Server function - either
"Enabled" or "Disabled".
For additional information about the PCs on your LAN, and the
IP addresses allocated to them, use the PC Database option on
the Administration menu.
Wireless
Network Name
(SSID) If using an ESS (Extended Service Set, with multiple access
points) this ID is called an ESSID (Extended Service Set Identi-
fier).
802.11 Mode The current 802.11 mode is displayed here.
Channel This shows the Channel currently used, as set on the Wireless
screen.
Security This indicates the Wireless security system currently used.
System
Device Name This displays the current name of the Wireless Router.
Firmware Version The current version of the firmware installed in the Wireless
Router.
Buttons
Connection Details View the details of the current Internet connection. The sub-
screen displayed will depend on the connection method used. See
the following sections for details of each sub-screen.
System Data Display all system information in a sub-window.
Restart Clicking this button will restart (reboot) the Wireless Router. All
existing connections though the Wireless Router will be termi-
nated, but will usually re-connect automatically.
Refresh Screen Update the data displayed on screen.
Connection Status - PPPoE
If using PPPoE (PPP over Ethernet), a screen like the following example will be displayed
when the "Connection Details" button is clicked.
41
