AirLive RS-1200 - Manual (Page 52)

52
Chapter 4
Address
The RS-1200 allows the Administrator to set Interface addresses of the
LAN network, LAN network group, WAN network, WAN network group,
DMZ and DMZ group.
An IP address in the Address Table can be an address of a computer or a
sub network. The Administrator can assign an easily recognized name to
an
IP address. Based on the network it belongs to, an IP address can be an
LAN
IP address, WAN IP address or DMZ IP address. If the Administrator needs
to create a control policy for packets of different IP addresses, he can first
add a new group in the LAN Group or the WAN Group and assign those IP
addresses into the newly created group. Using group addresses can
greatly simplify the process of building control policies.
With easily recognized names of IP addresses and names of address groups
shown in the address table, the Administrator can use these names as the source
address or destination address of control policies. The address table should be setup
before creating control policies, so that the Administrator can pick the names of correct
IP addresses from the address table when setting up control policies.
