81 AirLive OD-300CAM User ’s Manual
APPENDIX b
– STORAGE REQUIREMENT TABLE
This chapter provides tables that help you set your recording storage system.
Please refer to the following table to find out the capability for recording into your hard disk.
B.1 MPEG4 Storage Requirement GB / channel / day @ 30fps
Quality 640*480 320*240 160*120
Excellent 10.5 3.2 0.9
Detailed 4.2 1.6 0.5
Good 3.2 1.1 0.3
Standard 2.6 0.7 0.3
Medium 2.6 0.6 0.2
B.2 MPEG4 Storage Requirement GB / channel / day @ 15fps
Quality 640*480 320*240 160*120
Excellent 5.3 1.6 0.4
Detailed 2.1 0.8 0.3
Good 1.6 0.6 0.2
Standard 1.3 0.4 0.1
Medium 1.3 0.3 0.1
B.3 MPEG4 Storage Requirement GB / channel / day
Image-Size Bitrate Setting Frame-Rate Setting Current Bitrate
640*480 2048 30 23.0
640*480 2048 15 22.2
640*480 1536 30 18.5
640*480 1536 15 17.9
640*480 1024 30 10.5
640*480 1024 15 10.5
640*480 512 30 5.3
640*480 512 15 6.3
320*240 1536 30 15.8
320*240 1536 15 16.9
320*240 1024 30 10.5
320*240 1024 15 10.5
320*240 512 30 5.8
320*240 512 15 6.3
160*120 1024 30 10.0
160*120 1024 15 7.9
160*120 512 30 5.3
160*120 512 15 0.5
160*120 128 30 1.4
160*120 128 15 1.5
What is Color Rolling?
Color Rolling means the color of digital image turns from white to blue, pink (or yellow) and return to white
again. Such a phenomenon of circling period is caused by IP Cam ’s DSP of CCD which is used under
traditional alternating current (AC) 50/60Hz of fluorescent light (or gaseous electric light). The fluorescent light
changes constantly due to the strength and color of alternating current are base on the speed of 8.3ms. Thus,
CCD must catch and calculate the correct white balance through DPS. Normally, CCD needs 100~150ms
