8. Specifications
53 AirLive N.TOP User’s Manual
8.2.2 Rate and Modulation
Data Rate:
- 802.11n (40MHz): MCS0-7, up to 300Mbps
- 802.11n (20MHz): MCS0-7, up to 144Mbps
- 802.11g: 6, 9, 12, 24, 36, 48,54Mbps
- 802.11b: 1, 2, 5.5, 11Mbps
Modulation
- 802.11b: DSSS (DBPSK, DQPSK, CCK)
- 802.11g: OFDM (BPSK, QPSK, 16‐QAM, 64‐QAM)
- 802.11n: OFDM(BPSK, QPSK, 16‐QAM, 64‐QAM)
Receiver Sensitivity
- 802.11b 11Mbps ≦ -88dBm +/- 1
- 802.11g 54Mbps ≦ -75dBm +/- 1
- 802.11n HT20 MCS7 ≦ -72dBm +/- 1
- 802.11n HT40 MCS7 ≦ -68dBm +/- 1
8.2.3 TX Output Power
ETSI (Europe) - About 20dBm max
8.2.4 Supported WLAN Mode
2.4 GHz (B + G + N)
2.4 GHz (B)
2.4 GHz (B + G)
2.4 GHz ( G)
8.2.5 Supported WLAN Encryption
64/128-bit WEP
WPA/WPA2-PSK support
802.1x Radius Support
8.3 Software Feature
8.3.1 Operation Mode
Access Point Mode (AP mode)
Client Mode (Station-Infrastructure)
AP Bridge-Point to Point Mode
AP Bridge-WDS Mode
Universal Repeater Mode
