8. Specifications
AirLive N.TOP User’s Manual 52
The specification of N.TOP is subject to change without notice. Please use the
information with caution.
8.1 Hardware Features
8.1.1 General Hardware Feature
1 x 10/100 Mbps Ethernet Port with Auto MDI/MDI-X Support
802.3af PoE Port (LAN) LAN, WLAN, PWR, Reset/WPS LED Indicators
Reversed SMA Female Antenna Port
LAN, WLAN, PWR, Reset/WPS LED Indicators
300N 2T2R 11b/g/n Radio
Up to 27dBm Output Power (20dBm in EU, 23dBm in the U.S.)
2MB Flash, 16MB SDRAM
Reset/WPS Button
8.1.2 Antenna
PiFa Antenna x 2 (2T2R MIMO Technology)
8.1.3 Power Supply
5VDC, 2A Switching Power Adapter
8.1.4 Dimension and Weight
Product Weight: 143 g
Product Size (L x W x H): 105 x 105 x 46 mm
8.1.5 EMI
FCC, CE
8.2 Radio Specifications
8.2.1 Frequency Band
2.4000~2.4835GHz (Industrial Scientific Medical Band)
