AirLive ES-6000 User Manual
Page 41
40
4.1.6 Mail Routing
IP Address of Mail Gateway
Enter the mail gateway IP address in this column, all outgoing mails will pass to mail gateway, and send to
recipient. Mail Routing also allows administrator arranging some mail services, such as mail backup or
auditing, to construct more completely mail services.
Assigning a Mail Server to Process E-Mails from Specific Domains or E-Mail Addresses
Step1.
Decides using which mail server to relay e-mail messages.
Step2.
Under Mail Management Æ Configure Æ Mail Routing, refer to the steps below to make
settings:
Click
New Entry
.
Specify of which Relayed Domain Name / Mail Address is to be relayed.
Specify a mail server in the Mail Relay Server IP / Domain Name field.
Specify a port number for creating a SMTP connection with the mail server.
Determine whether to employ SMTP authentication accordingly. (Figure 4-25)
Click
OK
to complete settings. (Figure 4-26)
Figure 4-25 Mail Routing Settings
Figure 4-26 Mail Routing Setting Completed
Step3.
E-mails sent from the ES-6000’s mail accounts to the domain name / mail address you specified
will be relayed by the mail server you designated
Supposed the Relayed Domain Name / Mail Address setting is given an asterisk (＊), then e-mail
delivery to the mail accounts, except for those of ES-6000, will be processed by the relay server you
designated.
