7. Application Example: Infrastructure
AirLive AirMax5X User’s Manual
59
In this chapter, you will learn how to utilize AirMax5X’s Access Point mode, Client
Infrastructure Mode, and WDS AP/Station mode in one application example.
7.1 Application Environment
I n this application example, an AirMax5X in Access Point mode is in the center of an
infrastructure topology with two virtual wireless networks. Each wireless network has its
own SSID, security Policy and Bandwidth policy.
Below is the general description about the devices of the network.
7
7.
Application Example:
Infrastructure
