17

2 - T

YPICAL

A

PPLICATIONS

&

H

OW TO

C

ONFIGURE

T

HEM

The router is an Ethernet Bridge/Router that supports frame relay

RAW 1490 permanent virtual circuits, frame relay encapsulated PPP

permanent virtual circuits and PPP leased lines. This section will

describe how to set up the router using each of its networking

functions.
The router may be configured as a simple Ethernet bridge, an Ethernet

IP router, an Ethernet IPX router, or a combination of the three.

When operating the router as a combination bridge/router simply

configures each of the components separately.

:

The configuration options described within this section are only for initial

set up and configuration purposes. For more information on all of the

configuration parameters available, please refer to the router PPP Menus

Reference Manual file on the accompanying CD-ROM.

Important:

The router uses FLASH memory to store the

configuration information. Configuration settings are

stored to FLASH memory after there has been 30 seconds

of idle time. Idle time is when there is no selection or

modification of the values in the built-in menu system. If

you wish to save the configuration immediately, enter

“=” to jump to the main menu, then select option “6” to

save the configuration.
