9
CPU 3 / 4 CPU 1 / 2
3. Plug your DVI monitor into the DVI Console port located on the unit’s rear panel and power on
the monitor.
4. Using the provided 44-pin cable set, plug the 44-pin connector into the Computer port(s) of
the switch.
5. At the other end of the cable, plug the USB, DVI-D and speaker connectors into their respec-
tive ports on the computer.
6. For GCS1004 only, plug the power adapter that came with your switch into a power source,
then plug the power adapter into the switch’s Power Jack.
7. Turn on the power to the computers.
3
5 4
6
