IOGear GCS1004 - Manual (Page 21)

21
Specifications
Function GCS1002 GCS1004
Computer Connections 2 4
Console Connections 1 1
Port Selection Hotkey, Mouse switch, Front panel pushbuttons
Connectors
Console
Ports
KB 1 x USB Type A F (Iron)
Video 1 x DVI-D F (White)
Mouse 1 x USB Type A F (Iron)
Speakers 1 x Mini Stereo Jack F (Green)
Computer
Port 1
KB/
Mouse/
Video/
Speakers
1 x 44-pin Connector F
Computer
Port 2
KB/
Mouse/
Video/
Speakers
N/A 1 x 44-pin Connector F
Power N/A 1 x DC Jack
Pushbuttons 2 (Green) 4 (Green)
Cable Length 4ft x 1 (44-pin) 4ft x 1, 6ft x 1 (44-pin)
Power Consumption DC 5.0V, 5.0W DC 5.3V, 5.3W
Emulation KB / Mouse USB
Video 1920 x 1200 @60Hz
Scan Interval 3, 5, 10, 20 seconds (5s default)
Environment
Operating Temp. 0-50ºC
Storage Temp. -20-60ºC
Humidity 0-80% RH, Non-condensing
Physical
Properties
Housing Metal
Weight 0.33kg 0.51kg
Dimensions
(L x W x H)
12.30 x 7.54 x 2.28cm 19.80 x 7.54 x 2.28cm
