Hardware Installation
Cable Connections:
To set up your GCS1002 / GCS1004, refer to the installation diagram (the numbers in the
diagram correspond to the steps below), and follow the steps below:
1. Plug your speakers into the Audio port located on the unit’s side panel (optional).
2. Plug your USB keyboard and mouse into the USB Console ports located on the unit’s
side panel.
Note: The USB mouse port can also be used for other USB peripherals that you want
share between the computers with mouse emulation off.
Make sure that power to all the devices you will be installing has been turned off. You must
unplug the power cords of any computers that have the Keyboard Power On function.
Audio
2
1
2
