17
Field Explanation
Device Name: To make it easier to manage installations that have more than one
GCN1000, each one can be given a name. To assign a name
for the GCN1000, type in one of your choosing (16 characters max.).
MAC Address: Displays the GCN1000’s MAC Address.
Firmware Version: Indicates the GCN1000’s current fi rmware version level.
An explanation of each of the fi elds is given in the table below:
Network
The Network dialog is used to specify the GCN1000’s network environment.
Access Ports
If a fi rewall is being used, the Administrator can specify (in the Firewall’s set up) the port numbers that the
fi rewall will allow. Users must specify the port number as part of the IP address when they connect to the
GCN1000. If an invalid port number (or no port number) is specifi ed, the GCN1000 will not be found. I.E.
192.168.0.60 / 9000 (for the Windows client) and 192.168.0.60/9002 for the Java client.
Explanations of the fi elds are given in the table below:
Field Explanation
Program This is the port number that must be specified when connecting
from the Administrator and Windows Client. Valid entries are
between 1024 -60,000
Java This is the port number used for Java connections. Valid entries are
between 1 - 65535
