SECTION 2 TURNTABLE
S
E
C
T
I
O
N
2
T
U
R
N
T
A
B
L
E
0251233 3° TILT INDICATOR INSTALLATION Ref. A
44 4360171 Sensor, Level - 5° 1
2820022 Tubing, Vinyl 6 in.
4300106 Stud, Grooved 2
45 4360280 Sensor, Level - 3° 1
0239585 TURNTABLE LOCK INSTALLATION Ref. B
46 3421565 Pin, Snapper 1
47 3421565 Pin, Quick Release 2
1260017 Chain 9 in.
48 3421627 Pin, Lock 1
0251240 MANUAL DESCENT INSTALLATION - OPTIONAL
(PRIOR TO SEPTEMBER 1992) Ref. B
0253167 MANUAL DESCENT INSTALLATION - OPTIONAL
(SEPTEMBER 1992 TO PRESENT) Ref. B
49 4640005 Valve, Needle A/R
2900062 Valve, Kit 4
50 0901732 Bracket 1
51 3311601 Nut 3/8”-16NC 2
52 4761600 Lockwasher 3/8” 2
53 4751600 Flatwasher 3/8” 2
4300034 Stud (Welded on Part) 2
— — — — — — — — — —
1701428 Nametag - 1 1
1701494 Nametag - 2 1
1701426 Nametag - 3 1
1701463 Nametag - 4 1
1701462 Nametag - 5 1
1701778 Nametag - 6 1
0251415 HAND PUMP INSTALLATION (USE WITH
OPTIONAL MANUAL DESCENT) Ref. C
54 3600179 Pump, Manual with Handle (Includes Item 59) 1
7016673 Pump, Manual - w/o Handle 1
2900779 Seal Kit
55 0641609 Bolt 3/8”-16NC x 1 1/8” 2
56 4751600 Flatwasher 3/8” 2
57 4761600 Lockwasher 3/8” 2
58 3311601 Nut 3/8”-16NC 2
59 7010652 Handle, Pump 1
60 1380136 Clip, Gripper 2
61 3941003 Screw, Self-Tapping #10 2
62 4640603 Valve, Relief 1
2900770 Seal Kit
63 0641414 Bolt 1/4”-20NC X 1 3/4” 1
FIGURE 2-1. CONTROL VALVES INSTALLATION (CONTINUED)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
