3120806 5-3
SECTION 5 CYLINDER
S
E
C
T
I
O
N
5
C
Y
L
I
N
D
E
R
FIGURE 5-1. AXLE LOCKOUT CYLINDER ASSEMBLIES - 2WD (PRIOR TO SEPTEMBER 1992) (USE
WITH OPTIONAL OSCILLATING AXLE)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
1682376 AXLE LOCKOUT CYLINDER ASSEMBLY - 2WD
(PRIOR TO SEPTEMBER 1992) (USE WITH OPTIONAL
OSCILLATING AXLE) Ref. A
1 1682377 Barrel 1
2 4640273 Bleeder 3
3 3300187 Nut, Special (Prior to August 1992) 1
3300273 Nut, Hex (August 1992 to September 1992) 1
0100011 Loctite #242 A/R
0100038 Primer, Locking A/R
4 3951403 Setscrew 1/4”-20NC x 3/8” 3
3900170 Setscrew 3/8”-16NC x 3/8” 1
5 Kit Ring, Guidelock 2
6 Kit Seal 2
7 Kit O-Ring 1
8 3480116 Piston 1
9 4562859 Spacer 1
10 Kit O-Ring 1
11 Kit Ring 1
12 1681322 Head 1
13 Kit Seal, Rod 1
14 Kit Seal, Wiper 1
15 1120108 Retainer, Head 1
0100035 Loctite #222 A/R
16 1681462 Rod 1
17 2160002 Fitting, Grease 1
18 4640438 Cartridge, Check Valve 2
2900770 Seal Kit - 4640438 Valve (1 Per Valve) 2
19 2220237 Plug 2
— — — — — — — — — —
2900379 Kit, Seal (Includes Items 5,6,7,10,11,13 and 14) 1
