1-12 3120806
SECTION 1 FRAME
S
E
C
T
I
O
N
1
F
R
A
M
E
0251594 FRONT STEERING AND SPINDLES INSTALLATION
- 4WD (PRIOR TO FEBRUARY 1994) Ref. E
0251913 FRONT STEERING AND SPINDLES INSTALLATION
- 4WD (DOMESTIC BUILT FEBRUARY 1994 TO
PRESENT) Ref. D
81 1681555 Steer Cylinder Assembly (4WD Front) (See Section 5
for Breakdown) 1
82 3431622 Pin, Clevis 1
83 4712600 Flatwasher 1
84 3450606 Pin, Cotter 1
85 0630439 Bolt, Special 1
86 0440091 Washer, Thrust 1
87 3312602 Nut, Jam 1”-8NC 1
0100011 Loctite #242 A/R
88 2160002 Fitting, Grease 1
2160003 Fitting, Grease - 45° 4
4640182 Valve, Relief 4
89 3840868 Rod, Tie (4WD Front) 1
90 0560714 Block, Tie Rod (Left Side) 1
0560605 Block, Tie Rod (Right Side - Not Shown) 1
91 3300229 Nut, Jam (Left Side) 1
3323402 Nut, Jam (Right Side - Not Shown) 1
92 3312601 Nut 1”-8NC 2
93 0440091 Washer, Thrust 2
0100011 Loctite A/R
94 4130255 Spindle (Right Side) (4WD Front) 1
95 4130256 Spindle (Left Side) (4WD Front) 1
96 3421856 Kingpin (Top) (Prior to February 1994) 4
3421927 Kingpin (Top) (February 1994 to Present) 4
3780184 O-Ring 4
97 3421858 Kingpin (Bottom) (Prior to February 1994) 4
3421929 Kingpin (Bottom) (February 1994 to Present) 4
3780184 O-Ring 4
98 0440082 Bearing, Thrust (When Equipped) 2
99 0630083 Bolt, Special 8
100 4761600 Lockwasher 3/8” 8
4920096 Wire, Safety A/R
0251541 REAR STEERING AND SPINDLES INSTALLATION -
2WD Ref. C
0251593 REAR STEERING AND SPINDLES INSTALLATION -
4WD (PRIOR TO FEBRUARY 1994) Ref. E
0251914 REAR STEERING AND SPINDLES INSTALLATION -
4WD (FEBRUARY 1994 TO PRESENT) Ref. C
101 1682203 Steer Cylinder Assembly (2WD Rear) (See Section 5
for Breakdown) 1
1681555 Steer Cylinder Assembly (4WD Rear) (See Section 5
for Breakdown) 1
FIGURE 1-2. FRAME, STEERING AND AXLE INSTALLATIONS - 2WD AND 4WD (WITH 4 WHEEL
STEER) (CONTINUED)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
