1-10 3120806
SECTION 1 FRAME
S
E
C
T
I
O
N
1
F
R
A
M
E
28 3311601 Nut 3/8”-16NC 1
4761600 Lockwasher 3/8” 1
4300030 Stud (Welded on Parts) 1
29 2160002 Fitting, Grease 3
30 2160003 Fitting, Grease - 45° 1
31 0560951 Block, Axle (2WD with Fixed Front Axle) 2
32 0641616 Bolt 3/8”-16NC x 2” 4
4751600 Flatwasher 3/8” 4
33 4070224 Shim - .12 A/R
4070225 Shim - .06 A/R
0100019 Loctite #271 A/R
0254294 FIXED FRONT AXLE INSTALLATION - 4WD Ref. A
0251703 OSCILLATING FRONT AXLE INSTALLATION - 4WD
(PRIOR TO SEPTEMBER 1992) Ref. C
0253123 OSCILLATING FRONT AXLE INSTALLATION - 4WD
(SEPTEMBER 1992 TO PRESENT) Ref. D
34 Lockout Cylinder Assembly Options (4WD with
Oscillating Axle) (See Section 5 for Breakdown): 2
1682406 Cylinder (Prior to September 1992)
1682757 Cylinder (TUV) (September 1992 to Present)
35 3421861 Pin (Bottom) 2
36 4843286 Pin (Top) 2
37 0641407 Bolt 1/4”-20NC x 7/8” 4
38 4761400 Lockwasher 1/4” 4
39 4751400 Flatwasher 1/4” 4
40 4843826 Axle Weldment (4WD) 1
41 3422064 Pin (Prior to February 1994) 1
3422360 Pin (February 1994 to Present) 1
3780187 O-Ring (September 1992 to Present Only) (Not
Shown) 2
42 0641610 Bolt 3/8”-16NC x 1 1/4” 1
43 4761600 Lockwasher 3/8” 1
44 4740185 Flatwasher, Hardened 1
45 0961529 Bushing, Bronze (Top) (Prior to May 1992) 2
0961686 Bushing, Bronze (Top) (May 1992 to February
1994) 2
0961776 Bushing, Bronze (Top) (February 1994 to Present) 2
46 0961509 Bushing, Bronze (Bottom) (Prior to May 1992) 2
0961687 Bushing, Bronze (Bottom) (May 1992 to February
1994) 2
0961777 Bushing, Bronze (Bottom) (February 1994 to Pres-
ent) 2
47 2160003 Fitting, Grease - 45° 3
2160002 Fitting, Grease - Straight 4
3780184 O-Ring (Not Shown) 8
4640812 Valve, Relief Fitting (Not Shown) 5
FIGURE 1-2. FRAME, STEERING AND AXLE INSTALLATIONS - 2WD AND 4WD (WITH 4 WHEEL
STEER) (CONTINUED)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
