2-62 3120806
SECTION 2 TURNTABLE
S
E
C
T
I
O
N
2
T
U
R
N
T
A
B
L
E
206 4761600 Lockwasher 3/8” 8
0250599 PUMP COUPLING INSTALLATION - HAYES OPTION Ref. -
211 1660183 Coupling 1
Note: Coupling internal Spines must be lubed with
Lithium based grease prior to Installation. Ref.
212 0080163 Adapter, Pump 1
213 0641607 Bolt 3/8”-16NC x 7/8 6
214 4761600 Lockwasher 3/8” 6
215 0641610 Bolt 3/8”-16NC x 1 1/4” 8
216 4761600 Lockwasher 3/8” 8
3020021 Grease, Coupling A/R
0250232 COLD WEATHER PACKAGE INSTALLATION (NOT
SHOWN) Ref. B
2580022 Heater, Engine Block 1
2580001 Heater, Battery 1
2000088 ENGINE COMPONENTS Ref.
7023667 Fitting, Tee (Water By-Pass) 1
7000867 Harness, Engine 1
7014677 Major Components Kit (Include 1 each of standard
carburetor, water pump, fuel pump, starter and alterna-
tor) (See figure 2-18 for carburetor replacement parts) 1
7010633 Pump, Fuel 1
Use 7012679 Starter (was p/n 7000868) 1
7000874 Alternator 1
7014678 Gasket and Ignition Kit (Includes upper and lower
gasket sets, thermostat, ring gear, belt, coil, ignition
module, voltage regulator, starter solenoid and hoses) 1
7000871 Coil 1
7000869 Module, Ignition 1
7000870 Regulation, Voltage 1
7022180 Ring Gear (132 Teeth) 1
7014679 Tune-up Kit (Includes 4 spark plugs, and 1 each of oil
filter, fuel filter, cap, rotor and wire set)
Use 7019932 Plugs, Spark (was p/n 7012595) 4
Use 7021869 Filter, Oil (was p/n 7014501) 1
7000646 Gasket, Carburetor 1
7024321 Gasket, Carburetor (Top) 1
7022153 Water Pump Assembly 1
7019931 Wire Set - Spark Plug 2
FIGURE 2-17. FORD LSG423 ENGINE INSTALLATION - WITH NOISE REDUCTION (FEBRUARY
1993 TO FEBRUARY 1995) (CONTINUED)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
