JLG 60HA Parts Manual User Manual
Page 293
3120806
8-3
SECTION 8 DECALS
S
E
C
T
I
O
N
8
D
E
C
A
L
S
FIGURE 8-1. DECALS INSTALLATION (PRIOR TO FEBRUARY 1992)
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
0239627
DECAL INSTALLATION (PRIOR TO FEBRUARY 1992)
Ref.
D
1
1700431
Decal - Stripe
57 ft.
2
1700978
Decal - Arrow
4
3
1700977
Decal - FWD
4
4
1700580
Decal - Electrocution
5
5
1700585
Decal - Crushing
5
6
1701205
Decal - 60HA
3
7
1700430
Decal - Fuel - Gasoline
1
1700428
Decal - Fuel - Diesel
1
8
1700756
Decal - Full/Add
1
9
1700419
Decal - Hydraulic OIl
1
10
Not Available
Nameplate - Serial Number
1
3820001
Rivet
4
11
1700584
Decal - Patent
1
12
1700593
Decal - Inspection
1
13
1700979
Decal - Top Gun (Boom Location)
2
14
1700640
Decal - Crushing
3
15
1700981
Decal - JLG
2
16
1700975
Decal - Lift Here
4
17
1700976
Decal - Tie Down
4
18
3251813
Nameplate - Made in USA
1
19
1700980
Decal - Top Gun (Upright Location)
1
20
0860520
Box, Manual Storage
1
3311405
Locknut 1/4”-20NC
4
4751400
Flatwasher 1/4”
4
1060279
Cable, Lanyard
1
0641408
Bolt 1/4”-20NC x 1”
1
4751400
Flatwasher 1/4”
2
3311405
Locknut 1/4”-20NC
1
21
1700157
Decal - Manual
1
22
1700037
Decal - Ground Controls
1
23
0961127
Bushing, Snap
1
0100010
Loctite
A/R
24
3251243
Nameplate - 120V
1
25
1700643
Decal - Important
1
26
1700582
Decal - Ground Control Operation
1
27
3251028
Decal - Dual Fuel
1
28
3252347
Nameplate - Footswitch (was p/n 3251766)
1
3820001
Rivet
4
29
1700477
Decal - Attach Belt
2
30
1700476
Decal - No Hands
1
31
1700818
Decal - LP Gas Liquid Withdraw System
1
32
Not Used
33
1700429
Decal - LP Gas
1
— — — — — — — — — —
2900750
Decal Kit (Includes Latest Decals - See Figure 8-2)
1
