2-56 3120806
SECTION 2 TURNTABLE
S
E
C
T
I
O
N
2
T
U
R
N
T
A
B
L
E
106 3311601 Nut 3/8”-16NC 2
107 4761600 Lockwasher 3/8” 2
108 4711600 Flatwasher 3/8” 2
4300034 Stud (Welded on Parts) 2
109 2720015 Hose, Fuel LIne 10 ft.
110 1320022 Clamp 2
111 2220317 Fitting, Barbed 1
4420001 Tape, Sealant A/R
112 0901708 Bracket, Radiator Support (Rear) 1
— — — — — — — — — —
4920959 Harness (Not Shown) 1
0250232 COLD WEATHER PACKAGE INSTALLATION (NOT
SHOWN) Ref. B
2580022 Heater, Engine Block 1
2580001 Heater, Battery 1
2000088 ENGINE COMPONENTS Ref.
7023667 Fitting, Tee (Water By-Pass) 1
7000867 Harness, Engine 1
7014677 Major Components Kit (Include 1 each of standard
carburetor, water pump, fuel pump, starter and alterna-
tor) (See figure 2-18 for carburetor replacement parts) 1
7010633 Pump, Fuel 1
Use 7012679 Starter (was p/n 7000868) 1
7000874 Alternator 1
7014678 Gasket and Ignition Kit (Includes upper and lower
gasket sets, thermostat, ring gear, belt, coil, ignition
module, voltage regulator, starter solenoid and hoses) 1
7000871 Coil 1
7000869 Module, Ignition 1
7000870 Regulation, Voltage 1
7022180 Ring Gear (132 Teeth) 1
7014679 Tune-up Kit (Includes 4 spark plugs, and 1 each of oil
filter, fuel filter, cap, rotor and wire set)
Use 7019932 Plugs, Spark (was p/n 7012595) 4
Use 7021869 Filter, Oil (was p/n 7014501) 1
7000646 Gasket, Carburetor 1
7024321 Gasket, Carburetor (Top) 1
7022153 Water Pump Assembly 1
7019931 Wire Set - Spark Plug 2
FIGURE 2-16. FORD LSG423 ENGINE INSTALLATIONS - WITHOUT NOISE REDUCTION (PRIOR TO
FEBRUARY 1993) (CONTINUED)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
