JLG 60HA Parts Manual - Manual (Page 106)

2-44 3120806
SECTION 2 TURNTABLE
S
E
C
T
I
O
N
2
T
U
R
N
T
A
B
L
E
24 2720178 Hose, Rubber (0250037 Installation) 1
2720351 Hose, Rubber (0252297 Installation) 1
25 4564493 Tube, Air Intake (0250037 Installation Only) 1
26 0080039 Elbow (0250037 Installation Only) 1
27 1340020 Air Cleaner Assembly 1
28 7004214 Element 1
29 0340002 Band, Mounting 2
0641406 Bolt 1/4”-20NC x 3/4” 4
4751400 Flatwasher 1/4” 4
3311405 Locknut 1/4”-20NC 4
30 1120161 Cap, Inlet (0250037 Installation Only) 1
31 2720058 Hose, Fuel Line (Supply) 10 ft.
32 2720271 Hose, Fuel Line (Return) 10 ft.
33 1320022 Clamp, Hose 4
34 2200805 Fitting, 90° Barbed (Fuel Supply) 1
2220273 Fitting, Reducer (Fuel Supply) 1
35 2180536 Fitting, Barbed (Fuel Return) 1
2220273 Fitting, Reducer (Fuel Return) 1
4420001 Tape, Sealant A/R
36 2420110 Sender, Oil Pressure (See end of this parts list for
options) 1
2180730 Fitting, Straight Connector 1
2200261 Fitting, Straight 1
2180104 Fitting, Nipple 1
37 4564413 Tailpipe (Standard - 0250037 Installation) 1
4565278 Tailpipe (Standard - 0252297 Installation) 1
4565988 Tube, Exhaust (Standard - 0252297 Installation) 1
4100025 Sleeve, Fiberglass (Standard - 0252297 Installation) 2 ft/.6m
4565162 Tube, Exhaust (With Spark Arrestor) 1
4565163 Tailpipe (With Spark Arrestor) 1
7000694 Muffler (Standard - Not Shown) 1
3220036 Arrestor, Spark (Optional - Not Shown) 1
38 1320019 Clamp, Muffler 2
39 4843372 Snorkel, Exhaust 1
40 0641406 Bolt 1/4”-20NC x 3/4” 4
4761400 Lockwasher 1/4” 4
3311405 Locknut 1/4”-20NC 4
41 0901705 Bracket, Muffler (Standard) 1
0901759 Bracket, Muffler (With Spark Arrestor Only) 1
42 1320176 Clamp, Muffler 1
43 1060099 Cable, Battery (Starter to Start Relay) 1
44 1060092 Cable, Battery (Start Relay to Aux. Relay) 1
45 1060129 Cable, Battery (Aux. Relay to Aux. Pump) 1
46 1060074 Cable, Battery (Positive - Battery to Aux. Relay) 1
47 1060172 Cable, Battery (Negative - Battery to Ground) 1
48 1060045 Cable, Battery (Engine to Ground) 1
49 3311601 Nut 3/8”-16NC 1
50 4761600 Lockwasher 3/8” 1
4300034 Stud (Welded on Part) 1
51 0400075 Battery 1
FIGURE 2-14. DEUTZ ENGINE INSTALLATION (CONTINUED)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
