3120806 5-11
SECTION 5 CYLINDER
S
E
C
T
I
O
N
5
C
Y
L
I
N
D
E
R
FIGURE 5-5. AXLE LOCKOUT CYLINDER ASSEMBLY - 4WD/4WS (PRIOR TO SEPTEMBER 1992)
(USE WITH OPTIONAL OSCILLATING AXLE)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
1682406 AXLE LOCKOUT CYLINDER ASSEMBLY - 4WD/4WS
(PRIOR TO SEPTEMBER 1992) (USE WITH OPTIONAL
OSCILLATING AXLE) Ref. C
1 1682407 Barrel 1
2 4640273 Bleeder (Prior to April 1992) 2
3900175 Setscrew 1/4”-28NF x 3/4” (April 1992 to Present) 2
3960416 Seal, Thread (April 1992 to Present) 2
3321401 Nut 1/4”-28NF (April 1992 to Present) 2
3 3300187 Nut, Special (Prior to August 1992) 1
3300273 Nut, Hex (August 1992 to September 1992) 1
4 3900141 Setscrew 1/4”-20NC x 3/8” (Prior to August 1992) 2
3900170 Setscrew 3/8”-16NC x 3/8” (August 1992 to September
1992) 1
0100011 Loctite #242 A/R
0100038 Primer, Locking A/R
5 Kit Seal 1
6 Kit O-Ring 1
7 Kit Ring, Wear 1
8 3480120 Piston 1
9 4563647 Spacer 1
10 Kit O-Ring 1
11 Kit Ring, Backup 1
12 Kit Ring, Wear 1
13 1680892 Head 1
14 Kit Seal, Rod 1
15 Kit Seal, Wiper 1
16 1120179 Retainer, Head 1
0100035 Loctite #242 A/R
17 1681787 Rod 1
18 2160002 Fitting, Grease 1
19 4640438 Cartridge, Check Valve 2
2900770 Seal Kit (1 Per Valve) 2
20 2220885 Plug 2
— — — — — — — — — —
2900381 Kit, Seal (Includes Items 5,6,7,10,11,13 and 14) 1
