JLG 60HA Parts Manual User Manual
Page 122
2-60
3120806
SECTION 2 TURNTABLE
S
E
C
T
I
O
N
2
T
U
R
N
T
A
B
L
E
45
Not Used
46
0701010
Bolt, Metric 10mm x 20mm
7
47
4740116
Lockwasher, Metric 10mm
7
48
4564281
Tube, Oil Dipstick
1
49
2420109
Dipstick
1
50
4844337
Adapter, Exhaust
1
51
4921160
Harness
1
52
0901896
Bracket
1
53
2720015
Hose
1”/2.5cm
54
1320022
Clamp, Hose
1
55 to 66
Not Used
67
1120432
Cap, Vacuum
1
68
Not Used
69
4300056
Stud, Carburetor
1
0253711
ENGINE INSTALLATION - STANDARD GAS
INSTALLATION
Ref.
A
0253713
ENGINE INSTALLATION - DUAL FUEL
Ref.
B
0254218
EXHAUST INSTALLATION
Ref.
-
77
0641622
Bolt 3/8”-16NC x 2 3/4”
2
78
4751600
Flatwasher 3/8”
10
79
4761600
Lockwasher 3/8”
8
80
3311601
Nut 3/8”-16NC
6
81
0642022
Bolt 5/8”-11NC x 2 3/4”
2
82
0080201
Elbow
1
83
4762000
Lockwasher 5/8”
2
84
3312001
Nut 5/8”-11NC
2
85
0181691
Angle
1
86
3271501
Nut 5/16”-18NC (Grade 8)
3
87
4761400
Lockwasher 1/4”
5
88
3311401
Nut 5/16”-18NC
5
89
3620026
Radiator
1
90
3940804
Screw, Self-Tapping #8-32NC x 1/2”
6
91
4750800
Flatwasher #8
6
92
0630375
Bolt, Carriage 7/16”-14NC x 1”
2
93
4751700
Flatwasher 7/16”
2
94
4761700
Lockwasher 7/16”
2
95
3311701
Nut 7/16”-14NC
2
96
2680386
Shroud, Fan
1
97
4566007
Tube, Exhaust
1
98
4300031
Stud (Welded on Part)
4
99
4920959
Harness (Starter to Start Relay)
1
100
0641408
Bolt 1/4”-20NC x 1”
3
101
2220317
Fitting, Barbed
1
102
4420001
Tape, Sealant
A/R
103
2720015
Fuel LIne
10 ft/3m
104
1320022
Clamp
2
105
2200051
Plug, Pipe (Not Shown - Located on Tank)
1
FIGURE 2-17. FORD LSG423 ENGINE INSTALLATION - WITH NOISE REDUCTION (FEBRUARY
1993 TO FEBRUARY 1995) (CONTINUED)
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
