7-2 3120806
SECTION 7 ELECTRICAL
S
E
C
T
I
O
N
7
E
L
E
C
T
R
I
C
A
L
FIGURE 7-1.ELECTRICAL DIAGRAM LIST
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
ELECTRICAL DIAGRAM LIST Ref.
Note: Diagrams with asterisks (*) are shown in the
following pages. Diagrams not shown are available
from the JLG Service Department. Ref.
Alarm Electrical Diagrams Options Ref.
Machines Built Prior to January 1993:
4932024 Back-up Alarm with Lights Electrical Diagram Ref. —
0610091 Card, Circuit 1
3740049 Relay 1
4931947/1281985 Travel/Back-up/Swing Descent Electrical Dia-
gram Ref. G/G
0610091 Card, Circuit 1
3740049 Relay 1
4931946 Motion Electrical Diagram Ref. —
3990010 Diode - 6 Amp 2
3740049 Relay, Bosch - SPDT 1
0140016 Alarm, Horn 1
4932063 Tilt Electrical Diagram (3°) Ref. A
4931954 Tilt Electrical Diagram (5º) Ref. 3/C
4931950 Tilt Electrical Diagram (5° With Cut-Out) Ref. —
0140016 Alarm, Horn 1
3740049 Relay, Bosch - SPDT 1
4360089 Flasher - 12V (Without Cut-Out) 1
4360229 Switch, Toggle - SPDT M/C Override) (With Cut-
Out) 1
Machines Built January 1993 to Present: Ref.
4932637/1282091 Travel Electrical Diagram Ref. 2/D
0610104 Card, Circuit 1
4932639/1282091 Motion Electrical Diagram Ref. 2/D
3740049 Relay 1
3990010 Diode - 6 Amp 2
1060341 Cable, Electrical - 16/2 11ft./3.4m
0253077 Tilt Electrical Diagram Ref. A
0140026 Alarm 1
1540002 Capacitor 1
4932490 Australian Electrical Modification Ref. B
1281186 Cold Weather Electrical Diagram (Deutz) Ref. F
4932362/1281526 Collector Ring Electrical Diagram (4WS) Ref. A/C
1060042 Cable, Electrical - 16/5 14 ft.
4460260 Connector, Strain Relief (At Ground Control Box) 1
0960239 Bushing 1
3300047 Nut, Conduit 1
