SECTION 6 - JLG CONTROL SYSTEM
6-22 – JLG Lift – 3121813
6.10 ANALYZER DIAGNOSTICS MENU
STRUCTURE
In the following structure descriptions, an intended item is
selected by pressing ENTER; pressing ESC steps back to
the next outer level. The LEFT/RIGHT arrow keys move
between items in the same level. The UP/DOWN arrow
keys alter a value if allowed
Table 6-6. ADJUSTMENTS - Personality Descriptions
DRIVE
ACCEL … Displays/adjusts drive acceleration
DECEL … Displays/adjusts drive deceleration
MIN … Displays/adjusts minimum drive speed
MAX … Displays/adjusts maximum drive speed
ELEVATED MAX … Displays/adjusts maximum drive speed
NOTE: used when elevation cutout switches are limiting maximum speed
CREEP MAX … Displays/adjusts maximum drive speed
NOTE: used when creep switch on pump pot is active
TRACTION … Displays/adjusts the amount of time traction control is enabled after each input activation
POSITRAC … Displays/adjusts the maximum traction motor current at which positrac will activate
4WD MIN … Displays/adjusts the minimum 4WD assist speed
4WD MAX … Displays/adjusts the maximum 4WD assist speed
4WD CUTBACK … Displays/adjusts the maximum 4WD assist speed
NOTE: used when elevation cutout switches are limiting maximum speed
LIFT
ACCEL … Displays/adjusts upper lift acceleration
DECEL … Displays/adjusts upper lift deceleration
MIN UP … Displays/adjusts minimum upper lift up speed
MAX UP … Displays/adjusts maximum upper lift up speed
CREEP UP … Displays/adjusts maximum upper lift up speed
NOTE: used when creep switch on pump pot is active
MIN DOWN … Displays/adjusts minimum upper lift down speed
MAX DOWN … Displays/adjusts maximum upper lift down speed
CREEP DOWN … Displays/adjusts maximum upper lift down speed
NOTE: used when creep switch on pump pot is active
SWING
ACCEL … Displays/adjusts swing acceleration
DECEL … Displays/adjusts swing deceleration
MIN LEFT … Displays/adjusts minimum swing left speed
MAX LEFT … Displays/adjusts maximum swing left speed
