SECTION 6 - TROUBLESHOOTING
6-10
– JLG Lift –
3121228
Table 6-1. LCD Display - Service Fault Code Conditions
FAULT
CODE
PLATFORM
CONSOLE
LEDs
FLASHING
LCD SYMBOL SCREEN
LCD TEXT SCREEN
FAULT DESCRIPTION/
MACHINE CONDITION
TROUBLESHOOTING
—
—
—
Machine In Drive Speed
Cut-Back (Turtle) Mode
All The Time
Page 6-17
—
—
Brakes Released
DRIVE Disabled
Engage Brakes -
Press Brake Release Button
on Ground Control Station
—
—
—
Charger AC Plugged In
DRIVE Disabled
Unplug Charger
AC Input Power Cord
from Machine
—
—
Programmable Security
Lock Password
Type in Code At PSL Key Pad
See Operators Manual for
Proper Operation
01
1
Low Battery Voltage
Page 6-18
02
2
RESERVED
RESERVED
03
2
RESERVED
RESERVED
04
3
Tilt Condition
(Platform Elevated)
DRIVE and Lift UP Disabled
Page 6-19
05
—
RESERVED
RESERVED
06
8
Drive Motor
Brush Wear Warning
(Counts down 25 hrs. of
DRIVE operation remaining
to a 10 sec. shut down mode)
Drive Motor Brushes Require
Service Replacement -
(See Section 3.5, Wheel
Drive Assembly - Servicing
for further Instructions)
07
6
Left Drive Motor
Disconnected
DRIVE Disabled
Page 6-19
08
6
Right Drive Motor
Disconnected
DRIVE Disabled
Page 6-20
09
6
Left Brake Disconnected
DRIVE, Lift UP/DOWN
Disabled
Page 6-20
00000.0
00000.0
00000.0
00000.0
01
01
00000.0
04
04
00000.0
07
07
00000.0
08
08
00000.0
09
09
00000.0
