SECTION 5 - GENERAL SPECIFICATIONS AND OPERATOR MAINTENANCE
5-2 – JLG Lift – 3121186
5.2 GENERAL SPECIFICATIONS
Machine Specifications
SPECIFICATION SSV-10
Gross Machine Weight:
(Platform Empty): 1000 lb.
(454 kg)
Machine Height:
(Platform Stowed): 57 in.
(1.44m)
Maximum Ground Bearing Pressure:
(per wheel) 650 lb.
(295 kg)
Machine Under Clearance: 1.875 in.
(47.6mm)
Machine Turning Radius:
(Circle) 65 in.
(165cm)
Maximum Operating Incline: 1.5°
Maximum Travel Grade (Gradeability):
(Platform STOWED ONLY)
15%
Maximum Travel Grade (Side Slope):
(Platform STOWED ONLY)
5°
Maximum Drive Speeds:
(Operator Variable): 0.6 - 4 mph
(0.9 - 6.4 kph)
Machine Base - Overall :
(Width x Length) 29.5 in. W x 60 in. L
(75 cm W x 152 cm L)
Maximum Wind Speed: ANSI/CSA: 28 mph (12.5 m/s)
(For indoor use only) - CE: 0 mph (0 m/s)
(For indoor use only) - AUSTRAILIA: 0 mph (0 m/s)
Maximum Horizontal Manual Side Force:
(Platform fully extended with Maximum load) 45 Pound Force
(200 Newtons)
Maximum Hydraulic System Pressure:
(Recommended initial setting) 1800 PSI
(124 Bars)
Hydraulic System Capacity: 5 qts. U.S. (4.7 L)
Hydraulic Reservoir Capacity: 1 Gallon (3.78 L)
SPECIFICATION SSV-10
