SECTION 2 TURNTABLE
S
E
C
T
I
O
N
2
T
U
R
N
T
A
B
L
E
10
3420085
Pin, Clevis 1 1/4" x 5/16"
1
11
3450610
Pin, Cotter 3/16" x 2 1/2"
2
12
Pin, Cross Options:
1
3421165
Prior to January 1988
1
3421520
January 1988 to Present
1
13
3530120
Plate, Retainer
1
14
4761600
Lockwasher 3/8"
3
15
4751600
Flatwasher 3/8"
2
16
0641606
Bolt 3/8"-16NC x 3/4"
1
17
0651608
Bolt 3/8"-24NF x 1"
1
18
0641811
Bolt 1/2"-13NC x 1 3/8"
4
19
0100019
Loctite #271 (Not Shown)
A/R
20
4740277
Flatwasher
1
21
4740006
Flatwasher
1
22
0236548
Pin
1
23
4300034
Stud (Not Shown)
1
24 to 25
Not Used
26
3311601
Nut 3/8"-16NC
1
27
Not Used
28
0960562
Bushing, Self-Aligning (Part of Turntable Weldment)
2
29
1120192
Cap, Boom Pivot
2
30
0681808
Bolt 1/2"-13NC x 1" (Grade 8)
4
31
3952016
Setscrew 5/8"-11NC x 2"
2
32 to 33
Not Used
34
3312002
Nut, Jam 5/8"-11NC
2
35
2160006
Fitting, Grease
2
36 to 50
Not Used
51
Boom Assembly Options
(See Section 3 for Breakdown):
1
80HX & 80H:
0800662
ANSI Spec 80HX & 80H Built Prior To May 1992
0800807
ANSI Spec 80HX & 80H Built May 1992 To
Present
0800814
ANSI Spec 80HX & 80H With Chip Covers
0801016
ANSI Spec 80HX & 80H With Inverted Power
Track
0801005
ANSI Spec 80HX & 80H With 1 1/4" Waterline
0800662
CSA Spec 80HX & 80H Built Prior To May 1992
0800807
CSA Spec 80HX & 80H Built May 1992 To
Present
0800619
Hydraulic Controls 80HX & 80H Built Prior To
May 1992
0800808
Hydraulic Controls 80HX & 80H Built May 1992
To Present
0800905
Hydraulic Controls 80HX & 80H With
Chip Covers
0801151
Modified 80HX
80HX+6 & 86H:
0800663
ANSI Spec 80HX+6 Built Prior To May 1992
FIGURE 2-1. BOOM, TURNTABLE AND BEARING LUBE INSTALLATION (CONTINUED)
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
