SECTION 3 BOOM
S
E
C
T
I
O
N
3
B
O
O
M
0238692
BOOM HOSE COVERS INSTALLATION (80HX+6 &
86HX ONLY)
Ref.
2
401
4842968
Tube Weldment
1
402
4060568
Shield (Without Notches)
2
403
4060673
Shield (With Notches)
1
404
Support, Line Options:
4
4340413
Prior to S/N 34105
4340636
S/N 34105 to Present
405
Stud (Welded on Part - Not Shown) Options:
8
4300036
Prior to S/N 34105
4300042
S/N 34105 to Present
406
4751400
Flatwasher 1/4" (Not Shown)
8
407
4761400
Lockwasher 1/4" (Not Shown)
8
408
3311401
Nut 1/4"-20NC (Not Shown)
8
0237192
BOOM LIMIT SWITCH INSTALLATION (80HX &
80HX+6)
Ref.
G
501
4360057
Switch, Limit
1
502
0200048
Arm, Actuator
1
503
1670367
Cover
1
504
4300032
Stud (Welded on Part)
4
505
4761400
Lockwasher 1/4"
4
506
3311401
Nut 1/4"-20NC
4
507
Not Used
508
4561061
Tube
1
509
3530138
Plate, Mounting (Not Shown)
1
510
0721014
Bolt #10-24NC x 1 3/4"
2
511
4761000
Lockwasher #10
2
512
4751000
Flatwasher #10
2
513 to 515
Not Used
516
4460049
Connector, Strain Relief
1
0253417
POWER TRACK CLAMPS INSTALLATION (MAY
1992 TO PRESENT)
Ref.
2
601
1320182
Bar, Clamp
2
602
0630458
U-Bolt
2
603
4751400
Flatwasher 1/4"
4
604
3311405
Locknut 1/4"-20 NC
4
605
4240018
Tie-Strap (Not Shown)
34
FIGURE 3-1. BOOM ASSEMBLIES (CONTINUED)
