JLG 80H ANSI Parts Manual User Manual
Page 409
3120272
6-13
S
E
C
T
I
O
N
6
H
Y
D
R
A
U
L
I
C
S
SECTION 6 HYDRAULICS
FIGURE 6-6. HYDRAULIC DIAGRAM - DRIVE (2WD/2WS)
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
2791239
HYDRAULIC DIAGRAM - DRIVE (80HX/80HX+6 2WD/
2WS FIXED AXLE)
Ref.
H
2792263
HYDRAULIC DIAGRAM - DRIVE (80HX/80HX+6 2WD/
2WS OSCILLATING AXLE)
Ref.
A
2791265
HYDRAULIC DIAGRAM - DRIVE (80H 2WD/2WS)
Ref.
G
1
2220800
Fitting, Straight (Fixed Axle)
5
2220833
Fitting, Straight (Oscillating Axle)
4
2
2751321
Hose
2
3
2220568
Fitting, 45°
2
4
0100020
Sealant, Thread (Not Shown)
A/R
5
2220435
Fitting
2
6
2751339
Hose
2
7
2750760
Hose (80HX/80HX+6 Fixed Axle)
1
2752454
Hose (80HX/80HX+6 Oscillating Axle)
1
2750891
Hose (80H)
1
8
2220465
Fitting, 90°
2
9
4100051
Sleeve, Nylon (Oscillating Axle Only)
2
10
2220622
Fitting, Reducer (Oscillating Axle Only)
2
11
2220362
Fitting, Tee
1
12
2220582
Fitting, Straight
1
13
2220481
Fitting, Tee (Oscillating Axle)
1
2220362
Fitting, Tee (Fixed Axle)
1
14
2750762
Hose (Oscillating Axle Only)
1
15
2220451
Fitting, Straight
2
16
2752500
Hose
1
17
2751013
Hose (80HX/80HX+6 Fixed Axle)
1
2751398
Hose (80HX/80HX+6 Oscillating Axle)
1
2751021
Hose (80H)
1
18
2750791
Hose (Oscillating Axle Only)
1
19
2750977
Hose (80HX/80HX+6 Fixed Axle)
2
2750777
Hose (80HX/80HX+6 Oscillating Axle)
2
2750774
Hose (80H)
2
20
2220466
Fitting, 90° (Fixed Axle)
1
2220711
Fitting, Tee (Oscillating Axle)
1
21
2750891
Hose (80HX/80HX+6 Fixed Axle)
2
2750894
Hose (80HX/80HX+6 Oscillating Axle)
2
2751010
Hose (80H)
2
22
2220466
Fitting, 90°
2
23
2751472
Hose (80HX/80HX+6 Fixed Axle)
2
2751465
Hose (80HX/80HX+6 Oscillating Axle)
2
2750776
Hose (80H)
2
24
2220415
Fitting, Straight (Fixed Axle)
2
2220466
Fitting, 90° (Oscillating Axle)
2
25
2220504
Fitting, Tee
2
26
Not Used
27
2220868
Fitting
1
28
Not Used
