SECTION 2 TURNTABLE
FIGURE 2-32. GENERATOR INSTALLATION - FORD ENGINE MACHINES BUILT PRIOR TO MARCH
1995 (OPTIONAL)
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
GENERATOR INSTALLATION (STANDARD PARTS)
Ref.
1
Not Used
2
0641508
Bolt 5/16"-18NC x 1"
3
3
4761500
Lockwasher 5/8"
4
4
V-Belt Options:
1
0480037
(Prior to May 1987)
0480048
(May 1987 to March 1995)
5
3580134
Pulley (Part of Item 6)
1
6
2460011
Generator and Control Box Assembly
1
7012558
Generator Assembly
1
7020193
Cable, Generator (Generator to Control Box)
1
7026199
Armature
1
7020108
Brush
4
7020109
Holder, Brush
4
7012513
Cap, Brush Holder
4
7012514
Fan
1
7020110
Bell, Front
1
7020111
Bell Rear
1
7020190
Bearing
2
7003657
Control Box Assembly
1
Note: Replacement 110V Control Box comes
with 2 std Receptacles p/n 4460190. Optional
Industrial Twist Lock Receptacles p/n 4460027
must be ordered separately.
4360542
Breaker, Circuit
1
2420203
Voltmeter 110V (was p/n 7010699)
1
Receptacle Options:
4460190
Receptacle, Standard 110V
A/R
4460027
Receptacle, Twistlock 110V
2920162
Lamp
1
7020191
Switch, Toggle
1
3520028
Plug, Hole
1
7
Not Used
8
4751500
Flatwasher 5/16"
1
9 to 10
Not Used
11
0701021
Bolt, Metric 10mm x 65mm
2
12 to 15
Not Used
16
0721004
Screw, Machine #10-24NC x 1/2"
2
17
4751000
Flatwasher #10
4
18
4761000
Lockwasher #10
2
19
3311001
Nut #10-24NC
2
20
Not Used
21
3251476
Decal - On/Off
1
22
1060012
Cable, Electrical - 12/4
A/R
23
4460134
Connector (Not Shown - Located at Generator)
1
24
4460071
Connector (Not Shown - Located at Ground Control
Box)
1
