SECTION 6 HYDRAULICS
FIGURE 6-14. HYDRAULIC DIAGRAM - PUMP (HYDRAULIC CONTROLS)
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
2791985
HYDRAULIC DIAGRAM - PUMP (HYDRAULIC
CONTROLS)
Ref.
A
1
2720244
Hose, Suction (2 Sections - 30" Each Length)
A/R
2
1320031
Clamp
8
3
2220809
Fitting, 45°
1
4
2220808
Fitting, 45°
1
5
2220451
Fitting, Straight
2
6
Not Used
7
Not Used
8
Not Used
9
2220681
Fitting, Tee
1
10
2220621
Fitting, Reducer
2
11
2751004
Hose
1
12
2220371
Fitting, Straight
1
13
2751337
Hose
1
14
2220375
Fitting, Straight
1
15
Not Used
16
Not Used
17
Not Used
18
Not Used
19
2220618
Fitting, Reducer
2
20
2750889
Hose
1
21
2220415
Fitting, Straight
1
22
2220114
Fitting, 90°
1
23
2750127
Hose
1
24
2220070
Fitting, 90°1
1
25
2751467
Hose
1
26
2220635
Fitting, Tee
1
27
2220596
Fitting, 90°
1
28
2220902
Fitting, Tee
1
29
2220413
Fitting, 90°
1
30
2220582
Fitting, Straight
24
31
2750900
Hose
3
32
2220684
Fitting, Tee
1
33
2750872
Hose
1
34
2220738
Fitting, Tee
1
35
2220622
Fitting, Reducer
2
36
2751494
Hose
1
37
2220373
Fitting, Straight
1
38
2220472
Fitting, 90°
22
39
2220414
Fitting, Straight
2
40
4640197
Valve, Check
1
41
2220673
Fitting, 90°
1
42
4640575
Valve, Check
2
43
Not Used
44
Not Used
45
2750902
Hose
5
