JLG 80H ANSI Parts Manual User Manual
Page 310
4-6
3120272
SECTION 4 PLATFORMS
S
E
C
T
I
O
N
4
P
L
A
T
F
O
R
M
S
205
4740199
Washer, Thrust
4
206
0440120
Bearing, Thrust
2
207
2440043
Gear, Worm
1
208
3440816
Rollpin 1/4" x 1"
4
209
0080098
Adapter, Motor to Worm Gear
1
210
2440044
Gear, Worm
1
211
4740256
Washer, Thrust
2
212
0440135
Bearing, Sleeve
1
213
1760068
Disc, Brake (Note: Bolt Holes Not Drilled In
Replacement Disc)
1
214
Not Used
215
3931010
Bolt, Socket Head #10-24NC x 5/8"
5
216
3441228
Rollpin 3/8" x 1 3/4"
2
217
3931620
Bolt, Socket Head 3/8"-16NC x 1 1/4"
2
218
4761600
Lockwasher 3/8"
6
219
3931612
Bolt, Socket Head 3/8"-16NC x 3/4"
4
220
4070585
Shim.010
A/R
221
4070586
Shim.005
A/R
222
4070587
Shim.002
A/R
223
0100019
Loctite #271 (Not Shown)
A/R
224
0100021
Primer (Not Shown)
A/R
225
2160001
Fitting, Grease - 90°
1
226
3020025
Grease (Not Shown)
A/R
PLATFORM WELDMENTS
Ref.
Note: Replacement Decals Must Be Ordered Sep-
arately - See Section 8.
Ref.
301
Standard Platform Options:
1
3’ x 4’ (91.5cm x 123cm):
80HX & 80H:
3510138
Platform (Prior to July 1993)
3510438
Platform (July 1993 to Present)
80HX+6/86HX:
3510439
Platform
3’ x 5’ (91.5cm x 152.5cm):
80HX & 80H:
3510141
Platform with PQ Controllers (Prior to
September 1990)
3510150
Platform with OEM Controllers (Prior to
September 1990)
3510268
Platform (September 1990 to Present)
3510353
Platform with Slide Bar and Kickplates
3510234
Platform with Welded-on Bumper
3510268
Platform with Chain-Attached Bumper
3510512
Platform with Mesh to Top Rail
80HX+6/86HX:
3510271
Platform
3510319
Platform with Welded-on Bumper
3510271
Platform with Chain Attached Bumper
FIGURE 4-1. STANDARD PLATFORM AND FOOTSWITCH INSTALLATION. (CONTINUED)
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
