SECTION 9
RECOMMENDED SERVICE PARTS STOCK
MODELS 80HX/80HX+6 (STANDARD CONTROLS)
The following list will service fleets of machines (built to current production per date on the front cover) with
emergency repair parts which can be installed in the field. Parts from the list should be replaced when inven-
tory is depleted to keep service parts stock supplied. For further information, contact your JLG dealer or the
JLG Industries Parts Department.
JLG PART
NUMBER
DESCRIPTION
QTY PER FLEET
1-10
10-20
20 OR MORE
STANDARD PARTS
7012339
Coil - Vickers Valve (Figure 2-9)
1
1
1
7000417
Coil - Bang-Bang Valve (Dump) (Figure 2-11)
1
1
1
7002450
Coil - Bang-Bang Valve (Dump) (Figure 2-12)
1
1
1
7000418
Coil - Bang-Bang Valve (Working) (Figures 2-11 to 2-14)
1
1
1
7004214
Element, Air Filter (Figures 2-26 & 2-33)
4
8
12
3740067
Relay (Figures 2-26 & 2-33)
1
1
1
1340046
Breather, Hydraulic Tank (Figure 2-41)
4
8
12
2120107
Element, Hydraulic Oil Filter (Figure 2-41)
4
8
12
3740049
Relay - SPDT (Figures 2-43, 2-44 & 2-45)
1
1
1
3740016
Relay - 3PDT (Figures 2-43, 2-44 & 2-45)
1
1
1
4360186
Breaker, Circuit - 35 Amp (Figures 2-43, 2-44 & 2-45)
1
1
1
4360069
Breaker, Circuit - 10 Amp (Figures 2-43, 2-44 & 2-45)
1
1
1
4360466
Switch, Key (Figures 2-44 & 2-45)
1
1
1
2860030
Key (Figures 2-44 & 2-45)
2
4
6
4360199
Switch, Toggle - SPDT (Figures 2-43, 2-44, 2-45 & 4-6)
1
1
1
4360274
Switch, Push Button - SPST/MC (Figures 2-44, 2-45 & 4-6)
1
1
1
4360202
Switch, Toggle - DPDT/MC/CO (Figures 2-43, 2-44, 2-45 &
4-6)
1
1
1
4360201
Switch, Toggle - DPDT (Figures 2-44 & 2-45)
1
1
1
4360200
Switch, Toggle - DPDT/MC (Figures 2-44, 2-45 & 4-6)
1
1
1
3740057
Relay - 2PST (Figures 2-43, 2-44 & 2-45)
1
1
1
3740058
Relay - 4PDT (Figures 2-43, 2-44 & 2-45)
1
1
1
70002008
Power Track - 1 Foot Section (Figure 3-1)
2
2
2
2940006
Latch, Platform Door (Figures 4-1 & 4-2)
1
1
1
4360209
Breaker, Circuit - 20 Amp (Figure 4-6)
1
1
1
7011907
Electrical Assembly - 1600141 Controller (Figure 4-6)
1
1
1
7003751
Potentiometer (Figure 4-6)
1
1
1
4360475
Switch, Mushroom (Figure 4-6)
1
1
1
4360476
Contact, Switch Block (Figure 4-6)
1
1
1
3990010
Diode - 6 Amp (Figure 7-1)
2
2
2
VARIABLE PARTS
3740059
Relay (Deutz) (Figure 2-26)
1
1
1
7029276
Filter, Oil (Deutz Engine Machines) (Figure 2-25)
1 Dozen
1 Dozen
1 Dozen
3740080
Relay (Ford Engine Machines) (Figure 2-33)
1
1
1
7021869
Filter, Engine Oil (Ford Engine Machines) (Figure 2-33)
1 Dozen
1 Dozen
1 Dozen
4360212
Breaker, Circuit - 3 Amp (Deutz) (Figure 7-1)
1
1
2
4360057
Switch, Limit (Figure 1-17, 2-46 & 3-1)
1
2
2
4360277
Switch, Limit (Figure 1-17)
1
1
1
