SECTION 7 ELECTRICAL
0251683
Engine Run Light Wiring Diagram - Deutz
Engines
Ref.
B
2920027
Lamp, Indicator
1
2920029
Bulb, Light
1
4360037
Switch, Pressure
1
1702528
Decal - Engine Run
1
0256598
Engine Run Light Wiring Diagram - Ford Engines
Ref.
2
2920027
Lamp, Indicator
1
2920029
Bulb, Light
1
3990010
Diode
1
3252239
Decal - Engine Run
1
4932892
Engine Shut-Down Wiring Diagram - Deutz
Engines
Ref.
—
4931640
Extend-A-Reach Wiring Diagram (80HX+6/86HX
Only)
Ref.
C
4360202
Switch, Toggle - DPDT/MC (Located at Both Con-
trol Boxes)
2
3251747
Nameplate - Articulate (When Required)
2
4932434/
1281684
4WS Wiring Diagram (Without Axle Jacks)
Ref.
—/A
1060042
Cable, Electrical - 16/5
15 Ft.
4932847
4WS Wiring Diagram (With Dual Axle Jacks)
Ref.
B
1060341
Cable, Electrical - 16/2
20 Ft.
4921902
Harness, Axle Switches
1
4931693*
Generator Wiring Diagram - 110V (Deutz)
Ref.
E
3990001
Diode - 3.5 Amp
1
3740049
Relay
1
4360294
Breaker, Circuit - 30 Amp
1
4931314/
4931692
Generator Wiring Diagram - 110V (Ford) (Prior to
March 1995)
Ref.
C/D
3990001
Diode - 3.5 Amp
2
3740049
Relay
1
4360294
Breaker, Circuit - 30 Amp
1
4932806*
Generator Wiring Diagram - 110V (Ford) (March
1995 to Present)
Ref.
3/B
3990010
Diode - 6 Amp
3
4360294
Breaker, Circuit - 30 Amp
1
4932333
Glow Plugs Wiring Diagram
Ref.
A
3740067
Solenoid
1
4360274
Switch, Push Button
1
3252345
Nameplate - Choke/Glow Plug
1
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
