Page 68
Cab and Covers
4-2
G10-55A, G12-55A
4.1
OPERATOR’S CAB AND COVERS
COMPONENT TERMINOLOGY
To understand the safety, operation and maintenance
information presented in this section, it is necessary that
the operator/mechanic be familiar with the names and
locations of the major assemblies of the machine cab and
covers. The following illustration identifies the
components that are referred to throughout this section.
MY0930
TRANSMISSION
CONTROL LEVER
INSTRUMENT
PANEL
STEERING WHEEL
FRAME LEVEL
INDICATOR
BOOM CONTROL
JOYSTICK
HEATER AND A/C
CONTROLS (OPTIONAL)
ACCELERATOR
PEDAL
SERVICE BRAKE
PEDAL
IGNITION
SWITCH
SWAY CONTROL
JOYSTICK
AUXILIARY CONTROL
JOYSTICK
OUTRIGGER CONTROL
JOYSTICK
FUEL TANK
