SECTION 6 - GENERAL SPECIFICATIONS AND OPERATOR MAINTENANCE
6-2 – JLG Lift – 3128790
6.2 OPERATING SPECIFICATIONS
Dimensional Data
Chassis
Table 6-1. Operating Specifications
Model X700AJ
Maximum work load (capacity)
Unrestricted:
Restricted:
300 lbs (136 kg)
440 lbs (200 kg)
Max. Vertical Platform Height
Unrestricted:
Restricted:
76.1 ft (23.2 m)
71.5 ft (21.78 m)
Max. Horizontal Platform Reach
Unrestricted:
Restricted:
37.4 ft (9.61 m)
32.9 ft (11 m)
Table 6-2. Dimensional Data
Model X700AJ
Overall Width (with platform removed) 39 in (0.99m)
Outriggers Deployed Width 13 ft 1 in x 13 ft 1 in
(4.0 m x 4.0 m)
Stowed Height 6 ft 6 in (1.99m)
Stowed Length 19 ft 8 in (6m)
Approach angle with Jib lowered:
with Jib raised:
13°
25°
Departure angle 22°
Table 6-3. Chassis Data
Model X700AJ
Maximum Travel Grade w/ boom in stowed
position (gradeability) 15°
Maximum Travel Side Slope w/ boom in
stowed position 15° (27%)
Turning radius 0°
Maximum ground pressure per track (psi) 7 psi (0.49 kg/cm 2 )
Maximum ground pressure per outrigger 43 psi (3.0 kg/cm 2 )
Maximum outrigger pad load 4,720 lb (2,141 kg)
Outrigger pad diameter 11.8 in (300 mm)
Max drive speed 1.05 mph (1.7 km/hr)
Max hydraulic system pressure 2901 psi (200 bar)
Maximum wind speed 28 mph (12.5m/s)
Maximum manual force 90 lb (400 N)
Electrical system voltage 12V
Table 6-2. Dimensional Data
Model X700AJ
