SECTION 5 - EMERGENCY PROCEDURES
3128790 – JLG Lift – 5-11
For right side (operator's perspective) Outrigger
and Track Functions:
3. Install the pump handle on the pump and secure in
place with the provided screw. (item 3 - Figure 5-4.)
The lever on the pump must be set to the left to manu-
ally operate outrigger and track functions.
4. Locate the proportional flow valve on the left side of the
chassis attached to the group of four valves (item 1 -
Figure 5-5.). Turn the black knob on the valve clockwise
(tighten) until it stops.
5. With the aid of an assistant, activate the lever in the
desired direction on the appropriate valve solenoid
(valve description below) while pumping the pump han-
dle to achieve the desired function movement.
NOTE: If no assistant is available, the black thumbscrews on
the solenoids may be unscrewed to allow installation
of the valve tool on the solenoids.
• 1st valve (item 3 - Figure 5-5.) (far left (toward front of
machine) in the group of four) operates Right Front Out-
rigger.
• 2nd valve (item 4 - Figure 5-5.) from the left in the group
of four operates Right Rear Outrigger
• 3rd valve (item 5 - Figure 5-5.) from the left in the group
operates the Right Track Drive functions.
• 4th valve (item 6 - Figure 5-5.) operates track extension
and retraction.
For left side (operator's perspective) Outrigger and
Track Functions
6. Locate the proportional flow valve on the left side of the
chassis attached to the group of three valves (item 2 -
Figure 5-5.). Turn the black knob on the valve clockwise
(tighten) until it stops.
7. The lever on the pump must be set to the right to manu-
ally operate outrigger and track functions.
8. With the aid of an assistant, activate the lever in the
desired direction on the appropriate valve solenoid
while pumping the handle to achieve the desired func-
tion movement.
NOTE: If no assistant is available, the black thumbscrews on
the solenoids may be unscrewed to allow installation
of a second valve tool on the solenoids.
• 1st valve (item 7 - Figure 5-5.) (far left (toward front of
machine) in the group of three) operates Left Front Out-
rigger.
• 2nd valve (item 8 - Figure 5-5.) from the left in the group
of three operates Left Rear O/R. (lever up deploys Outrig-
ger.
• 3rd valve (item 9 - Figure 5-5.) from the left in the group
operates the Left Track Drive functions.
