Page 68

Transmission
6-2
L2906H, 2906H, 3507H, 619A, 723A, 29.6LP, 29.6, 35.7
6.1
TRANSMISSION ASSEMBLY
COMPONENT TERMINOLOGY
To understand the safety, operation and maintenance
information presented in this section, it is necessary that
the operator/mechanic be familiar with the names and
locations of the major assemblies of the transmission.
The following illustration identifies the components that
are referred to throughout this section.
MZ5410
HYDROSTATIC
TRANSMISSION
REVERSE
RELIEF
VALVE
DIRECTIONAL
CONTROL VALVE
HYDROSTATIC
FILTER
FORWARD
RELIEF
VALVE
