9.71 L2906H, 2906H, 3507H, 619A, 723A, 29.6LP, 29.6, 35.7
Electrical System
AUXILIARY
FUNCTION-A
VALVE– SHORT TO
GROUND 33198 1 Deactivate output J2-9 Auxiliary
Function-A Valve.
Decouple/disable current feedback
input J3-14 Aux Return (Disables
Auxiliary Function-A and
Function-B).
Deactivate and inhibit the
Continuous Auxiliary Hydraulics
feature.
Turn OFF the Continuous Auxiliary
Hydraulics indicator.
The UGM detects a short to ground
at this output or the UGM detects a
CURRENT FEEDBACK LOST
condition and sets an internal flag to
determine if this fault condition is
the reason for the fault.
Power cycled.
AUXILIARY
FUNCTION-B VALVE
– OPEN CIRCUIT 33199 1 Deactivate output J2-20 Auxiliary
Function-B Valve.
Deactivate and inhibit the
Continuous Auxiliary Hydraulics
feature.
Turn OFF the Continuous Auxiliary
Hydraulics indicator.
The UGM detects an open circuit at
this output or the UGM detects a
CURRENT FEEDBACK LOST
condition and sets an internal flag to
determine if this fault condition is
the reason for the fault.
Power cycled.
AUXILIARY
FUNCTION-B VALVE
– SHORT TO
GROUND 33200 1 Deactivate output J2-20 Auxiliary
Function-B Valve.
Decouple/disable current feedback
input J3-14 Aux Return (Disables
Auxiliary Function-A and
Function-B).
Deactivate and inhibit the
Continuous Auxiliary Hydraulics
feature.
Turn OFF the Continuous Auxiliary
Hydraulics indicator.
The UGM detects a short to ground
at this output or the UGM detects a
CURRENT FEEDBACK LOST
condition and sets an internal flag to
determine if this fault condition is
the reason for the fault.
Power cycled.
STABILIZER/FRAME
LEVEL SPEED
VALVE –
OPEN CIRCUIT 33201 1 Deactivate output J1-3 Stabilizer
and Frame Level Speed Valve.
The UGM is not configured for a
3508, 3509, 4008, or 4009 and the
UGM detects an open circuit at this
output or the UGM detects a
CURRENT FEEDBACK LOST
condition and sets an internal flag to
determine if this fault condition is
the reason for the fault.
Power cycled.
STABILIZER/FRAME
LEVEL SPEED
VALVE – SHORT TO
BATTERY 33202 1 Deactivate output J1-3 Stabilizer
and Frame Level Speed Valve.
Decouple/disable current feedback
input J3-5 Stabilizer – Frame Level
Return (Disables Stabilizers and
Frame Leveling functions).
The UGM is not configured for a
3508, 3509, 4008, or 4009 and the
UGM detects a short to battery at
this output.
Power cycled.
STABILIZER/FRAME
LEVEL SPEED
VALVE – SHORT TO
GROUND 33203 1 Deactivate output J1-3 Stabilizer
and Frame Level Speed Valve.
Decouple/disable current feedback
input J3-5 Stabilizer – Frame Level
Return (Disables Stabilizers and
Frame Leveling functions).
The UGM is not configured for a
3508, 3509, 4008, or 4009 and the
UGM detects a short to ground at
this output or the UGM detects a
CURRENT FEEDBACK LOST
condition and sets an internal flag to
determine if this fault condition is
the reason for the fault.
Power cycled.
Message Fault
Code
Indicators Other Actions Taken Trigger for Fault Latch Until
