9.79 L2906H, 2906H, 3507H, 619A, 723A, 29.6LP, 29.6, 35.7
Electrical System
TRANSMISSION 1
COIL – SHORT TO
GROUND 33260 1 Deactivate output J1-7
Transmission 1 Coil.
Deactivate and inhibit activation of
J1-20 Transmission 2 Coil.
Flash the “Gear Selection” symbol
on the LCD of the cabin’s display.
A TRANSMISSION configuration of
HYDROSTATIC is configured and
the UGM detects a short to ground
at this output.
Power cycled.
TRANSMISSION D
COIL –
OPEN CIRCUIT 33261 1 Deactivate output J1-20
Transmission D Control Coil (Gear
will not be available for selection).
2 nd , 3 rd , and 4 th will be the only
available gear selections.
Flash the “Gear Selection” symbol
on the LCD of the cabin’s display.
A TRANSMISSION configuration of
POWERSHIFT is configured and
the UGM detects an open circuit at
this output.
Power cycled.
TRANSMISSION D
COIL – SHORT TO
BATTERY 33262 1 Deactivate output J1-20
Transmission D Control Coil.
Flash the “Gear Selection” symbol
on the LCD of the cabin’s display.
A TRANSMISSION configuration of
POWERSHIFT is configured and
the UGM detects a short to battery
at this output.
Power cycled.
TRANSMISSION D
COIL – SHORT TO
GROUND 33263 1 Deactivate output J1-20
Transmission D Control Coil.
2 nd , 3 rd , and 4 th will be the only
available gear selections.
Flash the “Gear Selection” symbol
on the LCD of the cabin’s display.
A TRANSMISSION configuration of
POWERSHIFT is configured and
the UGM detects a short to ground
at this output.
Power cycled.
TRANSMISSION 2
COIL –
OPEN CIRCUIT 33264 1 Deactivate output J1-20
Transmission 2 Coil.
Deactivate and inhibit activation of
J1-7 Transmission 1 Coil.
Maintain the last valid gear
selection.
Flash the “Gear Selection” symbol
on the LCD of the cabin’s display.
A TRANSMISSION configuration of
HYDROSTATIC is configured and
the UGM detects an open circuit at
this output.
Power cycled.
TRANSMISSION 2
COIL – SHORT TO
BATTERY 33265 1 Deactivate output J1-20
Transmission 2 Coil.
Deactivate and inhibit activation of
J1-7 Transmission 1 Coil.
Flash the “Gear Selection” symbol
on the LCD of the cabin’s display.
A TRANSMISSION configuration of
HYDROSTATIC is configured and
the UGM detects a short to battery
at this output.
Power cycled.
TRANSMISSION 2
COIL – SHORT TO
GROUND 33266 1 Deactivate output J1-20
Transmission 2 Coil.
Deactivate and inhibit activation of
J1-7 Transmission 1 Coil.
Flash the “Gear Selection” symbol
on the LCD of the cabin’s display.
A TRANSMISSION configuration of
HYDROSTATIC is configured and
the UGM detects a short to ground
at this output.
Power cycled.
ENGINE FUEL
RELAY –
OPEN CIRCUIT 33267 1 Deactivate output J2-31 Engine
Fuel Relay.
Deactivate and inhibit output J2-26
Engage Starter.
The UGM detects an open circuit at
this output.
Power cycled.
Message Fault
Code
Indicators Other Actions Taken Trigger for Fault Latch Until
