Electrical System
JOYSTICK S3
BUTTON ACTIVE AT
POWER UP
219
1
Ignore command signals from the
joystick S3 button that was active
during the power-up.
At system power-up, if the S3 button
is activated on JLG models only.
A CAN
message is
received
indicating the
joystick S3
button is not
activated.
JOYSTICK S4
BUTTON ACTIVE AT
POWER UP
2110
1
Ignore command signals from the
joystick S4 button that was active
during the power-up.
At system power-up, if the S4 button
is activated on JLG models only.
A CAN
message is
received
indicating the
joystick S4
button is not
activated.
ENGINE START
PREVENTED –
PLATFORM START
SWITCH HIGH AT
POWER UP
2111
1
The engine start signal will be
ignored.
J2-26 Engage Starter will be
deactivated and inhibited.
If a LOW on J1-14 of the platform
module and the PLATFORM
STATION is active at system power
up.
Power cycled.
PLATFORM ROTATE
LEFT PREVENTED
– INPUT HIGH AT
POWER UP
2112
1
Ignore platform rotate left function
request.
If the PLATFORM STATION is
active and a platform is configured
as ENABLED and a platform is
detected as attached and a HIGH is
detected at the platform station on
the platform rotate left input at
system power up.
The input
goes LOW for
a period of at
least 1
second.
PLATFORM ROTATE
RIGHT PREVENTED
– INPUT HIGH AT
POWER UP
2113
1
Ignore platform rotate right function
request.
If the PLATFORM STATION is
active and a platform is configured
as ENABLED and a platform is
detected as attached and a HIGH is
detected at the platform station on
the platform rotate right input at
system power up.
The input
goes LOW for
a period of at
least 1
second.
PLATFORM LEVEL
UP PREVENTED –
INPUT HIGH AT
POWER UP
2114
1
Ignore platform level up function
request.
If the PLATFORM STATION is
active and a platform is configured
as ENABLED and a platform is
detected as attached and a HIGH is
detected at the platform station on
the platform level up input at system
power up.
The input
goes LOW for
a period of at
least 1
second.
PLATFORM LEVEL
DOWN PREVENTED
– INPUT HIGH AT
POWER UP
2115
1
Ignore platform level down function
request.
If the PLATFORM STATION is
active and a platform is configured
as ENABLED and a platform is
detected as attached and a HIGH is
detected at the platform station on
the platform level down input at
system power up.
The input
goes LOW for
a period of at
least 1
second.
Message
Fault
Code
Indicators
Other Actions Taken
Trigger for Fault
Latch Until
