Page 191

9.83
L2906H, 2906H, 3507H, 619A, 723A, 29.6LP, 29.6, 35.7
Electrical System
REAR AUXILIARY
HYDRAULICS
VALVE – SHORT TO
GROUND
33328
1
Deactivate output J2-23 Rear
Auxiliary Hydraulics Valve.
Deactivate output J2-9 Auxiliary
Function-A Valve until input J7-23
is LOW.
Deactivate output J2-20 Auxiliary
Function-B Valve until input J7-23
is LOW.
If the rear auxiliary hydraulics
feature is configured in the
MACHINE SETUP menu and the
UGM detects a short to ground at
this output.
Power cycled.
BOOM RIDE VALVE
– SHORT TO
BATTERY OR OPEN
CIRCUIT
33369
1
The Boom Ride feature will be
deactivated and inhibited.
If the Boom Ride feature is
configured and the Boom Ride/
Boom Float Module detects a short
to battery or open circuit at this
output.
Power cycled.
BOOM RIDE VALVE
– SHORT TO
GROUND
33338
1
The Boom Ride feature will be
deactivated and inhibited.
If the Boom Ride feature is
configured and the Boom Ride/
Boom Float Module detects a short
to ground at this output.
Power cycled.
BOOM FLOAT
VALVE – SHORT TO
BATTERY OR OPEN
CIRCUIT
33370
1
The Boom Float feature will be
deactivated and inhibited.
The Boom Ride feature will be
deactivated and inhibited.
J2-11 Main Lift Up Valve will be
inhibited.
If the Boom Float feature is
configured and the Boom Ride/
Boom Float Module detects a short
to battery or open circuit at this
output.
Power cycled.
BOOM FLOAT
VALVE – SHORT TO
GROUND
33341
1
The Boom Float feature will be
deactivated and inhibited.
J2-11 Main Lift Up Valve will be
inhibited.
If the Boom Float feature is
configured and the Boom Ride/
Boom Float Module detects a short
to ground at this output.
Power cycled.
BOOM TANK VALVE
– SHORT TO
BATTERY OR OPEN
CIRCUIT
33371
1
The Boom Ride feature will be
deactivated and inhibited.
The Boom Float feature will be
deactivated and inhibited.
J2-11 Main Lift Up Valve will be
inhibited.
If the Boom Ride or Boom Float
feature is configured and the Boom
Ride/Boom Float Module detects a
short to battery or open circuit at
this output.
Power cycled.
BOOM TANK VALVE
– SHORT TO
GROUND
33344
1
The Boom Ride feature will be
deactivated and inhibited.
The Boom Float feature will be
deactivated and inhibited.
If the Boom Ride or Boom Float
feature is configured and the Boom
Ride/Boom Float Module detects a
short to ground at this output.
Power cycled.
ENGINE
43XXX
Message
Fault
Code
Indicators
Other Actions Taken
Trigger for Fault
Latch Until
