Electrical System
ALL WHEEL STEER
VALVE – SHORT TO
GROUND
33275
1
Deactivate output J2-4 All Wheel
Steer Valve.
Try to complete any pending steer
mode changes.
Display the “Steer Valve Failure”
screen on the LCD of the cabin’s
display.
The UGM detects a short to ground
at this output.
Power cycled.
APU PUMP RELAY –
OPEN CIRCUIT
33276
1
Inhibit operation of J1-13 APU
Pump Relay.
The platform option is configured
and the UGM detects an open
circuit at this output.
Power cycled.
APU PUMP RELAY –
SHORT TO
BATTERY
33277
1
Inhibit operation of J1-13 APU
Pump Relay.
The platform option is configured
and the UGM detects a short to
battery at this output.
Power cycled.
APU PUMP RELAY –
SHORT TO
GROUND
33278
1
Inhibit operation of J1-13 APU
Pump Relay.
The platform option is configured
and the UGM detects a short to
ground at this output.
Power cycled.
GLOWPLUGS –
OPEN CIRCUIT
33279
1, 2
Deactivate output J1-12 Glow-
plugs.
The UGM detects an open circuit at
this output.
Power cycled.
GLOWPLUGS –
SHORT TO
BATTERY
33280
1, 2
Deactivate output J1-12 Glow-
plugs.
The UGM detects a short to battery
at this output.
Power cycled.
GLOWPLUGS -
SHORT TO
GROUND
33281
1, 2
Deactivate output J1-12 Glow-
plugs.
The UGM detects a short to ground
at this output.
Power cycled.
ENGAGE STARTER
OUTPUT – OPEN
CIRCUIT
33282
1
Deactivate output J2-26 Engage
Starter.
The UGM detects an open circuit at
this output.
Power cycled.
ENGAGE STARTER
OUTPUT – SHORT
TO BATTERY
33283
1
Deactivate output J2-26 Engage
Starter.
Activate output J2-31 Fuel Enable
Signal.
The UGM detects a short to battery
at this output.
Power cycled.
ENGAGE STARTER
OUTPUT – SHORT
TO GROUND
33284
1
Deactivate output J2-26 Engage
Starter.
The UGM detects a short to ground
at this output.
Power cycled.
ALTERNATOR
EXCITATION LINE –
SHORT TO
BATTERY
33285
1, 2, 10
J1-32 Alternator Excitation output
will be deactivated.
J1-32-Alternator Excite (and thus
J4-7 Alternator D+) is HIGH for a
period of 2 seconds or more and an
ENGINE STOPPED state is
detected.
Power cycled.
FRONT MOTOR –
CURRENT
FEEDBACK
READING TOO LOW
33286
1
N/A
The UGM detects the actual current
has deviated more than 250 mA
from the commanded current for
more than 1 second.
Power cycled.
Message
Fault
Code
Indicators
Other Actions Taken
Trigger for Fault
Latch Until
