Page 201

9.93
L2906H, 2906H, 3507H, 619A, 723A, 29.6LP, 29.6, 35.7
Electrical System
LSS CELL #3
ERROR
823
1, 14
Deactivate and inhibit the Lift Up
output.
Deactivate and inhibit the Lift Down
output.
Deactivate and inhibit the
Telescope Out output.
Deactivate and inhibit the
Telescope In output.
Deactivate and inhibit the Platform
Rotate Left output.
Deactivate and inhibit the Platform
Rotate Right output.
Deactivate and inhibit the Platform
Level Up output.
Deactivate and inhibit the Platform
Level Down output.
Deactivate platform module output
J2-19 Function Enable Relay.
Display the platform overloaded
screen on the cabin’s LCD.
The UGM has detected the
PLATFORM STATION is active and
the PLATFORM OPTION is
ENABLED and a platform is
detected as attached and the LSS
module is reporting a error with
regard to load cell #3.
Power cycled.
LSS CELL #4
ERROR
824
1, 14
Deactivate and inhibit the Lift Up
output.
Deactivate and inhibit the Lift Down
output.
Deactivate and inhibit the
Telescope Out output.
Deactivate and inhibit the
Telescope In output.
Deactivate and inhibit the Platform
Rotate Left output.
Deactivate and inhibit the Platform
Rotate Right output.
Deactivate and inhibit the Platform
Level Up output.
Deactivate and inhibit the Platform
Level Down output.
Deactivate platform module output
J2-19 Function Enable Relay.
Display the platform overloaded
screen on the cabin’s LCD.
The UGM has detected the
PLATFORM STATION is active and
the PLATFORM OPTION is
ENABLED and a platform is
detected as attached and the LSS
module is reporting a error with
regard to load cell #4.
Power cycled.
Message
Fault
Code
Indicators
Other Actions Taken
Trigger for Fault
Latch Until
